Models Available: 5E-C5808 Automatic Calorimeter (Ignition Wire) Standard Configuration:5E-C5808J Automatic Calorimeter (Laser Ignition Technology) Main analyzer Standard CV bomb -2 Units Crucibles Benzoic Acid O-ring kit Tool kit | Optional Configuration: Lens paper Pellet press Halogen Resistant Oxygen Vessel |
Features1. Patented laser ignition technology allowing easier and faster sample preparation, no ignition wire or cotton thread is needed(Available in 5E-C5808J model only)
2. 8min fast analysis for one sample
3. Automatic oxygen vessel lifting
4. Automatic oxygen charging and venting
5. Intelligent temperature control of the jacket and the water tank, the water constant temperature stability of the jacket reaches to 0.02℃
6. Easy and convenient touch screen operation
7. Small space occupied with compact design
8. Intelligent diagnosis and safety protection function
Model | 5E-C5808 / 5E-C5808J Automatic Calorimeter | |
Conforms to Method | AS 1038.5, ASTM D5865, ASTM D4809, ASTM E711, BIS 1350, BS EN 15400, GB/T 213,GB/T 30727, ISO 1928, ISO 9831, ISO 18125 | |
Precision (1g Benzoic Acid) | 0.05% RSD * | |
Measuring range | Up to 50000J | |
Heat Capacity Stability | ≤0.2% within one year | |
Temp.Resolution | 0.0001℃ | |
Control Ability | 2 Units/ 1 PC available | |
Analysis Time per Sample | 8mins | |
Jacket Type | Isoperibol and Adiabatic | |
Ignition Method | Patented Laser Technology - Available in 5E-C5808J model only | |
Bomb Identification | Yes | |
Balance Connection | Available | |
Network Connection | Available | |
Bucket Filling | Automatic | |
Oxygen Filling | Automatic | |
Bomb Vessel Lifting | Automatic | |
Structure | Benchtop | |
Power Supply | Single phase, AC220V±10%, 50/60Hz, ≤500w | |
Net Weight | 50kg | |
Dimensions(L×W×H) | 480mm×500mm×420mm | |
*Test Condition: 1. Ambient temp.20℃±1℃,humidity75%±5% 2.No strong interference source nearby 3.Clean water circuit with distilled water |
