บริษัท จรัญเอสโซซิเอทส์ จำกัด

ตู้แช่แข็ง - Fiocchetti - Freezer1500

TEL 087-8044747
฿0.00
ตู้แช่แข็ง - Fiocchetti - Freezer1500
เหลือ 0 ชิ้น
  • หมวดหมู่ : ตู้ควบคุมอุณหภูมืต่ำ
  • รหัสสินค้า : 001175

รายละเอียดสินค้า ตู้แช่แข็ง - Fiocchetti - Freezer1500




Characteristics
Temperature Range -10 / -25 °C
Capacity 1355 lt (47,87 cu ft)
External Dimensions (W x D x H) cm 144 x 82 x 205
Structure and Insulation sanitized pre-coated steel with bacteriostatic activity, white colour- in/out (rust- corrosion-proof material), or stainless steel 18/10 AISI 304 inside and sanitized pre-coated steel white colour- outside; insulation polyurethane thickness 70 mm
Feet n.4 adjustable feet
Door Nr 2 blind doors pre-coated steel white colour, with ergonomic handle in aluminum
Light Led type with adjustable brightness
Suggested internal fittings nr.6 shelves
Controller ECT-F TOUCH
Alarms Acoustic and Visual for temperature deviations and failures, with automatic recording
Safety Thermostat
Data and Event recording 10 years on SD card; last year on Flash-memory
Temperature Graph A customizable real time graphic always visible from the home page.
Connectivity USB-SD-SIM port with frontal access ; Dry Contact; Serial ports RS485 and RJ45
Refrigeration Type Forced-air, ventilated
Defrost Automatic with automatic evaporation of the condensate water

Technical data
Technical Data
In accordance with 2006/42/CE, 2014/30/CE, 2014/35/CE, 93/42/CE and following modifications
Package Strong Cardboard on wooden pallet




Accessories

Electric Digital Key Lock
Castors with brakes
Additional Shelf
Extractible Aluminum Drawer with partitions
Plexiglas front for drawers
Wire basket in stainless steel H mm 148
Sliding wire stainless steel drawer H mm 62
S/Steel Rack cm 14 x 50 x 15 H (max nr.3 each shelf)
Back-up Batteries
External Terminal Board for RS485/Ethernet/Dry Contact
Dmlp Digital Monitor Touch
GSM Module
Wi-fi Module
Cable port mm 35 with cap
Cable port mm 15
PT100 probe (free contacts)
Voltage stabilizer
4-20mA converter module
60 Hz Frequency
115 V
Wooden crate Package
