รายละเอียดสินค้า เครื่องหาค่าพลังงานความร้อน - CAL3K - AP

The CAL3K-AP Oxygen Bomb Calorimeter - Features

Exciting new features to improve your analytical experience.


Feature Description
No Water Required No water bucket. No measuring. No spillage.
Three Operating Modes IsothermalAdiabatic and ISOBATIC (and EXPERIMENTAL)
Automatic Oxygen Filling Automatic oxygen filling and de-filling of the reaction vessel.
Variable Filling Pressure Allows for variable filling pressure.
CalibrationFields For different modes and different calorimeters

CAL3K-AP Oxygen Bomb Calorimeter System - Digital Data Systems (Pty) Ltd.


Feature Description
High Speed Determinations Choose between faster or more accurate determinations.
Extremely Accurate Extremely Accurate (%RSD - 0.05%) determination eliminates multiple sample repeats.
Multiple Communication Channels 1 Wired (USB) and 2 optional wireless channels.
User Friendly User Friendly Operation
10 Calibration Average For variable amount of calibration average to suit your application
Low Power Consumption Very low power consumption. No temperature controlling required.
Eco Friendly Eco Friendly - small carbon footprint. No water, low power consumption.
Temperature Range Extensive Temperature Range from 0°C to 70°C.
Event Logging Built-in event logging for ±6000 events.
Fault Finding Extensive Fault Finding and Testing.
Temperature Accuracy Temperature accuracy of 10ppm (parts per million) (0.00001°C).
Results Results in MJ/Kg, KJ/g, BTU/Lb or Cal/g.
Compensation Compensation for firing energy and sulphur.
Preset Fields One default setting per mode.
Operating Parameters All operating parameters can be changed via the USB interface in the experimental mode.
Restrict Access Operating parameter access is password restricted.
Large Storage Up to 1024 results storage.
Intelligent Vessel Intelligent Vessel with built-in temperature sensing.
Linear Sensors Linear temperature sensing with platinum sensors.
Safety Continuous internal safety checks guarantee the safety of the operator.
Step-by-Step Help Screen prompts assist with step-by-step instructions to operate the calorimeter.
Bayonet Vessel Self-locking and self-sealing bayonet bomb vessel .
Air Cooler No water required to cool the bomb vessel .
Balance Interface Balance interface with baud speed setting.
Improved Initial Timing Based on drift and time, or time after drift.
Full LIMS Support For the assignment, scheduling, and tracking of samples.
Filter Data on Events Extensive testing and detailed data viewing.
Room Temperature Control No temperature control required.
Pressure Sensor / Leak Detection Detects leaks and aborts the firing in the vent of a leak.
Ports The unit has three available ports. USB and 2 x RS232 ports.

All the technical stuff

More information for the technically minded.


CAL3K-APDIMENSIONS


Width - 350mm

Height - 280mm

Depth - 240mm

Weight - 12kg

Power - 220-240V / 12W

AIR COOLER DIMENSIONS


Width - 155mm

Height - 235mm

Depth - 285mm

Weight - 3-4kg

Power - 12V

VESSEL DIMENSIONS


Diameter - 63mm

Height - 150mm

Weight - 1.9kg


Specification Information
Working (Operating) Temperature: 15-70°C
Storage Temperature: 0-70°C
Temperature Resolution: 0.000001°C
Reproducibility/Repeatability: <0.01% RSD
Resolution: 0.0001 MJ/Kg
Results per hour: 12 samples per hour using 3 bayonet bomb vessels
Measuring range max.: 99MJ, 99000J
Working temperature min.: 0°C
Working temperature max.: ~50°C
Cooling Medium: Air
Type of Cooling: Airflow
Oxygen Operating Pressure Max.: 40 bar
Balance/Scale Interface: RS232
Printer Interface: RS232
PC Interface: USB
Mobile App Interface: Bluetooth
Interface External Keyboard: PS2
Oxygen Filling: Automatic
Degasification: Automatic
Halogen (Decomposition) Vessel: Yes, optional
Analysis according to DIN 51900: Yes
Analysis according to ASTM D240: Yes
Analysis according to ASTM D4809: Yes
Analysis according to ASTM D5865: Yes
Analysis according to ASTM E711: Yes
Analysis according to ISO 1928: Yes
Dimensions: 350mm x 280mm x 240mm
Weight: ~12.000kg
Permissible Ambient Temperature: 0-35°C
Permissible Relative Humidity: 80%
RS232 Interface: Yes
USB Interface: Yes
Voltage: 220-240 / 100-120V, 12VDC, 3Amp
Frequency: 50/60Hz
Power Input: 12W

Please Note : Technical Specifications subject to change without prior notice. Please contact our team for accurate technical specification at the time.
